On Mei industrial grade IGBT single tube

Product	Description	Compliance	Status	V(BR)CES Typ (V)	IC Max (A)	VCE(sat) Typ (V)	VF Typ (V)	Eoff Typ (mJ)	Eon Typ (mJ)	Trr Typ (ns)	Irr Typ (A)	Gate Charge Typ (nC)	Short Circuit Withstand (µs)	EAS Typ (mJ)	PD Max (W)	Co-Packaged Diode	Package Type
FGH4L40T120LQD	IGBT, 1200V, 40A, Ultra Field Stop, Fast-switching Co-packed Diode.	Pb-free Halide free non AEC-Q and PPAP	ActiveNEW	1200	40	1.55	3.12	1.27	1.04	59	27.2	227	0	0	305	Yes	TO-247-4
FGH4L50T65SQD	IGBT - 650 V 50 A FS4 high speed IGBT with copack diode	Pb-free non AEC-Q and PPAP	ActiveNEW	650	50	1.6	2.1	0.44	0.66	29	14	92			268	Yes	TO-247-4
FGHL40T65LQDT	IGBT - 650 V 40 A FS4 low Vce(sat) IGBT with full rated copack diode	Pb-free non AEC-Q and PPAP	ActiveNEW	650	40	1.15	1.7	1.15	0.75	84	16	414			273	Yes	TO-247-3LD
FGHL50T65LQDT	IGBT - 650 V 50 A FS4 low Vce(sat) IGBT with full rated copack diode	Pb-free non AEC-Q and PPAP	ActiveNEW	650	50	1.15	1.65	1.48	1.18	75	21	509			341	Yes	TO-247-3LD
FGHL50T65LQDTL4	IGBT - 650 V 50 A FS4 low Vce(sat) IGBT with full rated copack diode	Pb-free non AEC-Q and PPAP	ActiveNEW	650	50	1.15	1.65	1.54	0.72	75	21	509			341	Yes	TO-247-4
FGHL75T65LQDT	IGBT - 650 V 75 A FS4 low Vce(sat) IGBT with full rated copack diode	Pb-free non AEC-Q and PPAP	ActiveNEW	650	75	1.15	1.65	2.38	1.88	87	18	793			469	Yes	TO-247-3LD
FGHL75T65LQDTL4	IGBT - 650 V 75 A FS4 low Vce(sat) IGBT with full rated copack diode	Pb-free non AEC-Q and PPAP	ActiveNEW	650	75	1.15	1.65	2.53	1.01	87	18	779			469	Yes	TO-247-4
FGA25N120ANTDTU	IGBT, 1200V, 25A, NPT Trench	Pb-free Halide free non AEC-Q and PPAP	Active	1200			2	0.96	4.1		27	200	-	-	312		TO-3P-3L
FGA3060ADF	IGBT, 600 V, 30 A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	600	30	1.8	1.6	0.165	0.96	26	-	37.4	-	-	176	Yes	TO-3P-3L
FGA30S120P	IGBT, 1300V, 30A, Shorted-anode	Pb-free Halide free non AEC-Q and PPAP	Active	1300	30	1.75	1.7	1.22	1.3	-	-	78	-	-	348	Yes	TO-3P-3L
FGA30T65SHD	IGBT, 650 V, 30 A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	650	30	1.6	2.2	0.167	0.598	192	-	54.7	-	-	238	Yes	TO-3P-3L
FGA40N65SMD	IGBT, 650V, 40A, Field Stop	Pb-free non AEC-Q and PPAP	Active	650	40	1.9	2.1	0.26	0.34	200	3.6	119	-	-	349	Yes	TO-3P-3L
FGA40T65SHD	IGBT, 650 V, 40 A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	650	40	1.6	2.2	0.297	1.01	192	-	72.2	-	-	268	Yes	TO-3P-3L
FGA40T65SHDF	IGBT, 650 V, 40 A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	650	40	1.45	1.5	0.44	1.22	238	-	68	-	-	268	Yes	TO-3P-3L
FGA5065ADF	IGBT, 650 V, 50 A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	650	50	1.7	2.1	0.309	1.35	192	-	72.2	-	-	268	Yes	TO-3P-3L
FGA50T65SHD	IGBT, 650 V, 50 A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	650	50	1.6	2.3	0.384	1.28	197	-	87	-	-	319	Yes	TO-3P-3L
FGA60N65SMD	IGBT, 650V, 60A, Field Stop	Pb-free non AEC-Q and PPAP	Active	650	60	1.9	2.1	0.45	1.54	212	-	189	-	-	600	Yes	TO-3P-3L
FGA6560WDF	IGBT, 650 V, 60 A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	650	60	1.8	1.8	0.52	2.46	271	-	84	-	-	306	Yes	TO-3P-3L
FGAF20S65AQ	IGBT, 650 V, 20A Field Stop Trench	Pb-free non AEC-Q and PPAP	Active	650	20	1.4	1.3	0.056	0.2	235		38			75	No	TO-3PF-3L
FGAF30S65AQ	IGBT, 650 V,30A Field Stop Trench	Pb-free non AEC-Q and PPAP	Active	650	30	1.4	1.3	0.082	0.295	267		58			83	No	TO-3PF-3L
FGAF40N60SMD	IGBT, 600V, 40A, Field Stop	Pb-free non AEC-Q and PPAP	Active	600	40	1.9	2.3	0.26	0.87	110	-	119	-	-	115	Yes	TO-3PF-3L
FGAF40N60UF	IGBT, 600V, PT	Pb-free non AEC-Q and PPAP	Active	600	20	2.3	-	0.13	0.47	-	-	77	-	-	100	No	TO-3PF-3L
FGAF40N60UFD	600V, PT IGBT	Pb-free non AEC-Q and PPAP	Active	600	20	2.3										Yes	TO-3PF-3L
FGAF40S65AQ	IGBT, 650 V, 40 A Field Stop Trench	Pb-free non AEC-Q and PPAP	Active	650	40	1.6	1.2	0.062	0.132	274	-	75	-	-	94	No	TO-3PF-3L
FGD3N60UNDF	IGBT, 600V, 3A, Short Circuit Rated	Pb-free Halide free non AEC-Q and PPAP	Active	600	3	2	1.7	0.3	0.52	21	-	1.6	10	-	60	Yes	DPAK-3 / TO-252-3
FGD4536TM	360 V PDP Trench IGBT	Pb-free Halide free non AEC-Q and PPAP	Active	360	220	1.59						47			125	No	DPAK-3 / TO-252-3
FGD5T120SH	IGBT, 1200 V, 5 A FS Trench	Pb-free Halide free non AEC-Q and PPAP	Active	1200	5	2.9	-	0.94	0.247	-	-	6.7	-	-	69	No	DPAK-3 / TO-252-3
FGH15T120SMD	IGBT, 1200V, 15A, Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	1200			2.8	0.46	1.15		12	128	-	-	333		TO-247-3
FGH20N60SFD	IGBT, 650V, 20A, 2.2V, TO-247<BR>High Speed Field Stop	Pb-free Halide free non AEC-Q and PPAP	Active	600	20	2.2	1.9	0.13	0.43	34	-	66	-	-	165	Yes	TO-247-3
FGH25T120SMD	IGBT, 1200V, 25A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	1200			2.8	0.56	1.74	325	13	225	-	-	428		TO-247-3
FGH30N60LSD	IGBT, 600V, 30A, PT	Pb-free Halide free non AEC-Q and PPAP	Active	600	30	1.1										Yes	TO-247-3
FGH30S130P	IGBT, 1300V, 30A, Shorted-anode	Pb-free Halide free non AEC-Q and PPAP	Active	1300	30	1.75	1.7	1.22	1.3	-	-	372.3	-	-	500	Yes	TO-247-3
FGH40N60SFD	IGBT, 600V, 40A, Field Stop	Pb-free Halide free non AEC-Q and PPAP	Active	600	40	2.3	1.8	0.38	1.23	68	-	121	-	-	290	Yes	TO-247-3
FGH40N60SMD	IGBT, 600V, 40A, 1.9V, TO-247<BR>Field Stop	Pb-free Halide free non AEC-Q and PPAP	Active	600	40	1.9	-	-	-	36	-	-	-	-	-	Yes	TO-247-3
FGH40N60SMDF	IGBT, 600V, 40A, 1.9V, TO-247<BR>Field Stop	Pb-free Halide free non AEC-Q and PPAP	Active	600	40	1.9	1.3	0.25	1.3	57	-	122	-	-	349	Yes	TO-247-3
FGH40N60UFD	IGBT, 600V, 40A, Field Stop	Pb-free Halide free non AEC-Q and PPAP	Active	600	40	1.8	1.95	0.46	1.19	45	-	120	-	-	290	Yes	TO-247-3
FGH40T100SMD	IGBT, 1000V, 40A, Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	1000			3.4	1.15	2.35		-	265	-	-	333		TO-247-3
FGH40T120SMD	IGBT, 1200V, 40A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	1200	40	1.8	3.8	1.1	2.7	200	18	370	-	-	555	Yes	TO-247-3
FGH40T120SQDNL4	IGBT, Ultra Field Stop	Pb-free Halide free non AEC-Q and PPAP	Active	1200	40	1.78	3.4	1.1	2.7	166	9	221	0		227	Yes	TO-247-4
FGH40T65SHD	IGBT, 650 V, 40 A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	650			2.2	0.297	1.01		-	72.2	-	-	268		TO-247-3
FGH40T65SHDF	IGBT, 650V, 40A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	650			1.5	0.44	1.22		-	68	-	-	268		TO-247-3
FGH40T65SQD	IGBT, 650 V, 40 A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	650	40	1.6	2.2	0.052	0.138	31.8	-	80	-	-	238	Yes	TO-247-3
FGH50N3	IGBT, 300V, SMPS	Pb-free non AEC-Q and PPAP	Active	300	75	1.3	-	0.92	0.13	-	-	180	8	800	463	No	TO-247-3
FGH50T65SQD-F155	IGBT, 650 V, 50A Field Stop 4 Trench	Pb-free Halide free non AEC-Q and PPAP	Active	650			2.2	0.11	0.402		-	99	-	-	268		TO-247-3
FGH60N60SFDTU	IGBT, Field Stop, 600V, 60A	Pb-free Halide free non AEC-Q and PPAP	Active	600	60	2.3	-	0.67	1.79	179	-	198	-	-	378	Yes	TO-247-3
FGH60N60SMD	IGBT, 600V, 60A, Field Stop	Pb-free Halide free non AEC-Q and PPAP	Active	600	60	1.9	2.1	0.39	1.59	72	-	187	-	-	600	Yes	TO-247-3
FGH60N60UFD	IGBT, 600V, 20A, 1.8V, TO-247<BR>Low VCE(ON) Field Stop	Pb-free Halide free non AEC-Q and PPAP	Active	600	60	1.8	1.7	0.81	2.47	47	-	192	-	-	298	Yes	TO-247-3
FGH60T65SHD	IGBT, 650 V, 60 A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	650			2.3	0.63	1.69		-	102	-	-	349		TO-247-3
FGH60T65SQD-F155	IGBT, 650 V, 60 A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	650	60	1.6	2.3	0.167	0.585	34.6		79			333		TO-247-3
FGH75T65SHD	IGBT, 650 V, 75 A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	650			2.2	0.72	2.4		-	123	-	-	455		TO-247-3
FGH75T65SHDT	IGBT, 650 V, 75 A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	650			1.8	0.75	3	76	-	123	-	-	455		TO-247-3
FGH75T65SHDTL4	IGBT, 650 V, 75 A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	650	75	1.6	1.8	1.56	1.06	76	-	126	-	-	455	Yes	TO-247-4
FGH75T65SQD	IGBT, 650 V, 75 A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	650			2	0.18	0.76		-	128	-	-	375		TO-247-3
FGH75T65SQDNL4	IGBT, Field Stop IV/4 Lead	Pb-free Halide free non AEC-Q and PPAP	Active	650	75	1.43	1.6	1.26	1.25	134	10	128			375	Yes	TO-247-4
FGH75T65SQDT	IGBT, 650 V, 75 A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	650	75	1.6	1.8	0.18	0.76	76	-	128	-	-	375	Yes	TO-247-3
FGH75T65SQDTL4	IGBT, 650 V, 75 A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	650	75	1.6	1.8	0.266	0.307	76	-	128	-	-	375	Yes	TO-247-4
FGH80N60FD2	IGBT, 600V, Field Stop	Pb-free Halide free non AEC-Q and PPAP	Active	600	40	1.8	1.2	0.52	1	125	4.8	120	-	-	290	Yes	TO-247-3
FGHL40T65MQD	IGBT - 650 V 40 A FS4 medium switching speed IGBT	Pb-free Halide free non AEC-Q and PPAP	Active	650	40	1.45	2.55	0.52	0.86	33		86			119	Yes	TO-247-3LD
FGHL40T65MQDT	IGBT - 650 V 40 A FS4 medium switching speed IGBT with full rated copack diode	Pb-free non AEC-Q and PPAP	Active	650	40	1.45	1.7	0.49	0.88	86		80			238	Yes	TO-247-3LD
FGHL50T65MQD	IGBT - 650 V 50 A FS4 medium switching speed IGBT	Pb-free Halide free non AEC-Q and PPAP	Active	650	50	1.45	2.45	0.7	1.05	32		94			134	Yes	TO-247-3LD
FGHL50T65MQDT	IGBT - 650 V 50 A FS4 medium switching speed IGBT with full rated copack diode	Pb-free non AEC-Q and PPAP	Active	650	50	1.45	1.65	0.63	1.19	79		99			268	Yes	TO-247-3LD
FGHL50T65MQDTL4	IGBT - 650 V 50 A FS4 medium switching speed IGBT with full rated copack diode	Pb-free non AEC-Q and PPAP	Active	650	50	1.45	1.65	0.85	1	79		99			268	Yes	TO-247-4
FGHL50T65SQ	IGBT 650V FS4 High speed version for PFC application in TO-247	Pb-free Halide free non AEC-Q and PPAP	Active	650	50	1.6	-	0.088	0.41	-	-	99	-	-	268	No	TO-247-3LD
FGHL50T65SQDT	IGBT, 650 V, 50 A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	650	50	1.47	2	0.22	0.26	201	-	99.7	-	-	268	Yes	TO-247-3LD
FGHL75T65MQD	IGBT - 650 V 75 A FS4 medium switching speed IGBT	Pb-free Halide free non AEC-Q and PPAP	Active	650	75	1.45	2.3	1.55	1.94	36	250	145			375	Yes	TO-247-3LD
FGHL75T65MQDT	IGBT - 650 V 75 A FS4 medium switching speed IGBT with full rated copack diode	Pb-free non AEC-Q and PPAP	Active	650	75	1.45	1.65	1.25	2.35	107		149			375	Yes	TO-247-3LD
FGHL75T65MQDTL4	IGBT - 650 V 75 A FS4 medium switching speed IGBT with full rated copack diode	Pb-free non AEC-Q and PPAP	Active	650	75	1.45	1.65	1.1	1.2	107		149			375	Yes	TO-247-4
FGL40N120AND	IGBT, 1200V, NPT	Pb-free Halide free non AEC-Q and PPAP	Active	1200	40	2.6	3.2	1.1	2.3	75	8	220	10	-	500	Yes	TO-264-3
FGPF15N60UNDF	IGBT, 600V, 15A, Short Circuit Rated	Pb-free non AEC-Q and PPAP	Active	600	15	2.2	1.6	0.067	0.37	142	-	43	-	-	42	Yes	TO-220-3 FullPak
FGY100T65SCDT	IGBT, Field Stop Trench, Short Circuit Rated, 650 V, 100 A	Pb-free Halide free non AEC-Q and PPAP	Active	650	100	1.5	1.68	5.2	9.7	62	-	157	5	-	750	Yes	TO-247-3
FGY40T120SMD	IGBT, 1200 V, 40 A Field Stop Trench	Pb-free Halide free non AEC-Q and PPAP	Active	1200	40	1.8	3.8	1.1	2.7	200	-	370	-	-	882	Yes	TO-247-3
FGY60T120SQDN	IGBT, Ultra Field Stop -1200V 60A	Pb-free Halide free non AEC-Q and PPAP	Active	1200	60	1.7											TO-247-3
FGY75T120SQDN	IGBT, Ultra Field Stop -1200V 75A	Pb-free Halide free non AEC-Q and PPAP	Active	1200	75	1.7	3.4	1.96	6.25	99	20	399			395	Yes	TO-247-3
FGY75T95SQDT	IGBT - 950 V 75 A Field stop trench IGBT	Pb-free non AEC-Q and PPAP	Active	950	75	1.69	2.03	1	2.1	105		137			434	Yes	TO-247-3
HGT1S10N120BNS	IGBT, 1200V, NPT	Pb-free non AEC-Q and PPAP	Active	1200	17	2.45	-	0.8	0.32	-	-	100	8	80	298	No	D2PAK-3 / TO-263-2
HGTD1N120BNS	IGBT, 1200V, NPT	Pb-free non AEC-Q and PPAP	Active	1200	2.7	2.5	-	0.09	0.07	-	-	14	8	10	60	No	DPAK-3 / TO-252-3
NGTB15N120FL2	IGBT 1200V 15A SOLAR/UPS	Pb-free Halide free non AEC-Q and PPAP	Active	1200	15	2	2	0.37	1.2	110	11	109	10	-	294	Yes	TO-247
NGTB25N120FL2	IGBT, 1200V 25A FS2 SOLAR/UPS	Pb-free Halide free non AEC-Q and PPAP	Active	1200	25	2	2.1	0.6	1.95	154	15	178	10	-	385	Yes	TO-247
NGTB25N120FL3	IGBT, Ultra Field Stop - 1200V 25A	Pb-free Halide free non AEC-Q and PPAP	Active	1200	25	1.7	3	0.7	1	90	12	136	-	-	349	Yes	TO-247
NGTB35N65FL2	IGBT, 650V 35A FS2 Solar/UPS	Pb-free Halide free non AEC-Q and PPAP	Active	650	35	1.7	2.2	0.28	0.84	68	7	125	5	-	300	Yes	TO-247
NGTB40N120FL2	IGBT, 1200V 40A FS2 Solar/UPS	Pb-free Halide free non AEC-Q and PPAP	Active	1200	40	2	2	1.1	3.4	240	18	313	10	-	535	Yes	TO-247
NGTB40N120FL3	IGBT, Ultra Field Stop -1200V 40A	Pb-free Halide free non AEC-Q and PPAP	Active	1200	40	1.7	3	1.1	1.6	86	12	212	-	-	454	Yes	TO-247
NGTB40N65FL2	IGBT, 650V 40A FS2 Solar/UPS	Pb-free Halide free non AEC-Q and PPAP	Active	650	40	1.7	2.2	0.44	0.97	72	6.7	170	5	-	366	Yes	TO-247
NGTB50N120FL2	IGBT, 1200V 50A FS2 Solar/UPS	Pb-free Halide free non AEC-Q and PPAP	Active	1200	50	2.2	2	1.4	4.4	256	19	311	10	-	535	Yes	TO-247
NGTB50N65FL2	IGBT, 650V 50A FS2 Solar/UPS	Pb-free Halide free non AEC-Q and PPAP	Active	650	50	1.8	2.1	0.46	1.5	94	8	220	5	-	417	Yes	TO-247
NGTB75N65FL2	IGBT, 650V 75A FS2 Solar/UPS	Pb-free Halide free non AEC-Q and PPAP	Active	650	75	1.7	2.2	1	1.5	80	8	310	5	-	595	Yes	TO-247
NGTD13T65F2	IGBT, 650V 30A FS2 bare die	Pb-free Halide free non AEC-Q and PPAP	Active	650	-	1.6	-	-	-	-	-	-	5	-	-	-
NGTD14T65F2	IGBT, 650V 35A FS2 bare die	Pb-free Halide free non AEC-Q and PPAP	Active	650	-	1.7	-	-	-	-	-	-	10	-	-	-
NGTD15R65F2	Rectifier 650V 75A FS2 bare die	Pb-free Halide free non AEC-Q and PPAP	Active	650	-	-	2.2	-	-	-	-	-	-	-	-	-
NGTD17T65F2	IGBT 600V 40A FS2 bare die	Pb-free Halide free non AEC-Q and PPAP	Active	650	-	1.7	-	-	-	-	-	-	5	-	-	-
NGTD20T120F2	IGBT 1200V 20A FS2 bare die	Pb-free Halide free non AEC-Q and PPAP	Active	1200	-	2	-	-	-	-	-	-	10	-	-	-
NGTD21T65F2	IGBT 650V 45A FS2 bare die	Pb-free Halide free non AEC-Q and PPAP	Active	650	-	1.7	-	-	-	-	-	-	5	-	-	-
NGTD23T120F2	IGBT 1200V 25A FS2 bare die	Pb-free Halide free non AEC-Q and PPAP	Active	1200	-	1.9	-	-	-	-	-	-	10	-	-	-
NGTD28T65F2	IGBT 650V 75A FS2 bare die	Pb-free Halide free non AEC-Q and PPAP	Active	650	-	1.75	-	-	-	-	-	-	5	-	-	-
NGTD5R65F2	Rectifier 650V 20A FS2 bare die	Pb-free Halide free non AEC-Q and PPAP	Active	650	-	-	1.1	-	-	-	-	-	-	-	-	-
NGTD8R65F2	Rectifier 650V 30A FS2 bare die	Pb-free Halide free non AEC-Q and PPAP	Active	650	-	-	2.1	-	-	-	-	-	-	-	-	-
NGTG12N60TF1G	IGBT, N-Channel, 600V, 12A, VCE(sat)=1.4V, TO-3PF-3L	Pb-free non AEC-Q and PPAP	Active	600	12	1.4	-	-	-	-	-	84	5	-	54	No	TO-3PF-3L
PCFG50T65SQF	650V 50A FS4 IGBT Wafer Sales	Pb-free Halide free non AEC-Q and PPAP	Active		50	1.6						99
PCFG75T65LQF	PCFG75T65LQF	Pb-free Halide free non AEC-Q and PPAP	Active
PCFG75T65MQF	IGBT 650V, 75A	Pb-free Halide free non AEC-Q and PPAP	Active
PCFG75T65SQF	650V 75A FS4 IGBT Wafer Sales	Pb-free Halide free non AEC-Q and PPAP	Active		75	1.6						128
SGF5N150UF	IGBT, Discrete, High Performance	Pb-free non AEC-Q and PPAP	Active	1500	10	4.7	-	0.1	0.19	-	-	30	-	-	62.5	No	TO-3PF-3L
